Available
5-port Management L2 and Gigabit managed switch with 2000 MAC table entry capacity
PORTS AND INTERFACES
Number and type of basic ports RJ-45 Ethernet: 5 Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper), number of ports: 5
CONNECTION
10G support : No
Link aggregation: Yes
Auto MDI / MDI-X: Yes
Auto-negotiation: Yes
Port mirroring: Yes
Network standards: IEEE 802.1p, IEEE 802.1 Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Virtual LAN Features: Port-based VLAN
Number of VLANs: 32
VLAN Support: Yes
Ethernet cabling technology Copper: 1000BASE-T, 100BASE-TX, 10BASE-T
POWER CONTROL
Power Consumption (max): 2.82 W
Input Current: 0.6 A
Power Source: DC
Power Supply Included: Yes
Input Voltage: 5V
ENVIRONMENTAL CONDITIONS
Heat Dissipation: 9.62 BTU/h
Operating Temperature Range: 0 - 40°C
Storage temperature range: -40 - 70 °C
Operating relative humidity range: 10 - 90%
Storage relative humidity range: 5 - 90%
WEIGHT AND DIMENSIONS:
Height : 26 mm
Width: 99.8 mm
Depth: 98 mm
SECURITY
IGMP: Yes
DATA TRANSMISSION
Switching capacity: 10 Gbit/s
Jumbo Frames, Support: Yes
Store and Forward: Yes
Jumbo Frames: 16000
MAC Address Table: 2000 entries
Packet Buffer: 1 MB
Forwarding Rate: 7.44 Mpps
MANAGEMENT FEATURES
Web-Based Management: Yes
Quality of Service (QoS) Support: Yes
Switch Layer: L2
Switch Type: Managed
POWER OVER ETHERNET (POE) )
Power over Ethernet (PoE): No
DESIGN
Certification: FCC, CE, RoHS
Product color: Black
LED indicators: Yes
