LOCOSYS LS26030-G and LS26031-G are GNSS modules incorporated into the PCIe Full-Mini card or PCIe Half-Mini card. The GNSS module is based on MediaTek advanced new generation MT3333 GNSS chip. It can provide you with superior sensitivity and performance even in urban canyon and dense foliage environment. Besides, the USB interface makes these modules easy to integrate into the laptop.
These modules support hybrid ephemeris prediction to achieve faster cold start. One is self-generated ephemeris prediction that is no need of both network assistance and host CPU’s intervention. This is valid for up to 3 days and updates automatically from time to time when GNSS module is powered on and satellites are available. The other is server-generated ephemeris prediction that gets from an internet server. This is valid for up to 14 days. Both ephemeris predictions are stored in the on-board flash memory and perform a cold start time less than 15 seconds
USB interface.
MediaTek high sensitivity solution.
Support GPS, GLONASS, GALILEO and QZSS.
Capable of SBAS (WAAS, EGNOS, MSAS, GAGAN).
Support 99-channel GNSS.
Low power consumption.
Fast TTFF at low signal level.
Built-in 12 multi-tone active interference canceller.
Free hybrid ephemeris prediction to achieve faster cold start.
Built-in data logger.
Up to 10 Hz update rate.
± 11ns high accuracy time pulse (1PPS).
Indoor and outdoor multi-path detection and compensation.
Built-in SAW filter and chip embedded LNA
Built-in micro battery to reserve system data for rapid satellite acquisition..
Applications:
Laptop with GNSS Function.
IPC with GNSS Function.
Machine to Machine.
Satellite System: GPS + QZSS + GALILEO + GLONASS
Interface: USB
Input Voltage: 3.0V - 3.6V
Power (mA): 40mA
VB (uA): 7uA
Operating Temp (°C): -40 ~ 85
Dimension (mm): PCIe Full / Half Mini Card
