The limit switch, also known as a micro switch or end-of-travel switch, is an electromechanical component designed to detect the end position of a moving part within an automated system. This medium-sized model with a 12 mm short lever and roller has been specifically developed for motion control, position detection, and status signalling in demanding industrial environments.
Its mechanical actuation by cam or direct contact ensures a precise and repeatable response, guaranteeing accurate cycle control in automatic machines, industrial robots, conveyor systems, and CNC equipment. The short lever with roller allows smooth and reliable activation even with minimal displacement, enhancing precision in high-performance applications.
This limit switch is equipped with 1NO + 1NC contacts rated at 16 A / 250 V, allowing switching or signal interruption in control and automation circuits. The high-strength polyamide housing provides excellent mechanical durability, while the silver-plated brass terminals ensure optimal electrical conductivity and corrosion resistance.
Designed to operate across a wide temperature range from -20 °C to +85 °C and manufactured in compliance with EN60947-5-1, this industrial micro switch is ideal for applications requiring precise end-of-travel detection, motion monitoring, and automated system protection.
