Anderson® SB50 Type Connector - Blue - AWG8

Ref. CT42SG50AZ

No disponible Product unavailable
Stock Quantity
0
Features

Anderson® connectors are hermaphroditic connectors that are generally used to handle high currents in batteries and similar applications

Connection terminals included



Specifications
  • Rated current: 50A
  • Rated voltage: 600 V
  • Insulation resistance: 5000Mohms
  • Contact resistance less than 0.055 ± 0.005 ohm
  • Life time:
    • Empty: up to 10,000 on / off
    • With load: 250 cycles at 120V / 40A
  • Flammability: UL94 V-0
  • Operating temperature: -20 ºC..125 ºC
  • Silver contacts: 1 µm Ag
  • Cable cross section: 8,37 mm² (AWG8)
  • Dimensions of the terminals:
    • A: 29.6 mm
    • B: 6.9 mm
    • C: 4.7 mm
    • D: 11 mm

Back to list » Price VAT INCLUDED 3.90
(For quantity order over 10 pìeces) -15.00% 3.31
