Musta CH-0187 - 4K 60Hz 18Gbps HDMI Cable - Straight Male to Male 90° Upward Angle - 3m

CX1A1094K

Sold out. We can let you know when it is available.

Quantity

VAT NOT INCLUDED

VAT INCLUDED

6.00 €

7.26 €

>=5 Pcs

5.40 €

6.53 €

>=25 Pcs

4.80 €

5.81 €

>=50 Pcs

4.50 €

5.45 €

>=100 Pcs

4.20 €

5.08 €

>=200 Pcs

3.90 €

4.72 €

Identification

EE Code CX1A1094K

Brand

Musta

Model CH-0187

Manufacturer code CH-0187

EAN13

Features

HDMI 4K, which is backward compatible with previous versions of the HDMI specification, significantly increases bandwidth to 18 Gbps and adds key enhancements to meet market demands and improve the consumer audio and video experience.

HDMI 4K significantly increases bandwidth to 18 Gbps and includes the following advanced features:

Resolutions up to 4K at 50/60 Hz (2160p), which is four times the sharpness of 1080p video resolution at 60 Hz, for an unparalleled video experience.
Up to 32 audio channels for an immersive, multidimensional audio experience.
Audio sampling rate up to 1536 kHz for maximum audio fidelity.
Simultaneous streaming of two video streams to multiple users on the same screen.
Simultaneous delivery of multi-channel audio to multiple users (up to 4).
Support for 21:9 widescreen video aspect ratio.
Dynamic synchronization of video and audio streams.
CEC extensions provide broader control and management of consumer electronics devices through a single control point.

Specifications

Connector Type	HDMI 19Pin Straight Male to HDMI 19Pin 90° Upward Angle
Connector Finish	Nickel/24K Gold Plated
Length	3 m
Gauge	22AWG/24AWG/26AWG/28AWG/30AWG/32AWG
Conductor Plating	Tinned Copper/OFC
Shielding Level	Triple
Shielding Type	EMI
Ferrite Cores	Yes
Net Jacket	No
Built-in Equalizer	No
Supported Resolutions	3840x2160, 60/50p
Bandwidth	up to 340 MHz per channel (1.8 GHz total)
Data Throughput	up to 3.4 Gbps per channel (18 Gbps total)
HDMI Certified	Yes
FC Compliant	Yes
CE Compliant	Yes
ROHS & Reach Compliant	Yes
Supports DVD Audio	Yes
Supports SACD	Yes
Supports Dolby TrueHD™ &DTS-HD Master Audio™	Yes
Voltage Rating	30V
